Transmission Line ASTM A123 Electrical Power Pole 110KV
  • Transmission Line ASTM A123 Electrical Power Pole 110KV
  • Transmission Line ASTM A123 Electrical Power Pole 110KV

Transmission Line ASTM A123 Electrical Power Pole 110KV

Herkunftsort China
Markenname JSHG
Zertifizierung ISO/CNAS/IAF/CA
Modellnummer HG-SP-110KV
Produkt-Details
Spannung:
110KV
Art:
besonders angefertigt
Grundplatte:
Quadrat/rundes/Polygon mit Schlitzöffnungen für Ankerbolzen und Maß gemäß der Anforderung des Kunden
Wandstärke:
3.0mm
Malen:
Entsprechend dem Antrag der Kunden
Leben-Zeitraum:
Mehr als 25 Jahre, ist es entsprechend der Installierung von Umwelt
Material:
Q345
Markieren:

Electrical Power Pole 110KV

,

ASTM A123 Electrical Power Pole

,

ASTM A123 Transmission Line Pole

Zahlungs-u. Verschiffen-Ausdrücke
Min Bestellmenge
Verkäuflich
Preis
negotiation
Verpackung Informationen
* bedeckt durch Plastikhülle oder Matte oder entsprechend den Anträgen des Kunden. * die Laden-PC je
Lieferzeit
2 Wochen pro Behälter nach PO/Zeichnung/der Vorauszahlung bestätigt
Zahlungsbedingungen
L/C, T/T oder Western Union
Versorgungsmaterial-Fähigkeit
3.000 metrische Tonnen pro Monat
Produkt-Beschreibung

NEA Standard Design Load Q345 Electrical Power Pole

Product Description:



Products
  • NEA Standard Design Load Q345 Electrical Power Pole

Application
  • Electrical power transmission line

Standrad
  • NEA Standard

Painting
  • According to clients' request

Shape
  • Customized

Galvanization
  • Hot dip galvanization of substation structure is in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.
Base plate
  • Square/round/Polygon with slotted holes for anchor bolt and dimension as per client’s requirement.



Product Advantages:

A. Management team: We have a professional design team to provide services for customers. Provide design drawings.

B. ISO 9001:2015 certificate provided .

C. QC Inspection: We have an inspector team to inspect the whole production line, and each pole should be inspected in accordance with the drawing, to make sure all poles are passed before delivery.



Transmission Line ASTM A123 Electrical Power Pole 110KV 0




Engineering and Design Management:

“Design and technology,professional and common, software and hardware” is JSHG‘s electric post design philosophy. We have established a close cooperative relationship with design institutions and companies in the same industry. Through close communication and explorations, our company took in advanced design concept, introducing domestic and foreign first-class design software, and attracting high-quality personnel.



In the R&D Department, there are many experienced senior research & design staff and rigid development network, which ensure our design proposals meet customer demand, even exceed their expectations.



Since the establishment, JSHG have put forward thousands of design proposals covering several industries and fields, such as power transmission industry, telecommunication industry, lighting industry, etc, which provides complete and strong technical support and service assurance.



Features:

1. We can supply the product base on client required drawing ,but also can supply the design for any kinds of lamp poles ,electric poles ,street lighting poles, high mast poles ,garden light poles , outdoor lighting ,outdoor lighting poles ,flag poles ,traffic light poles ,lighting ,road lighting pole.

2. Matercial :hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3

3. deal: Hot dip galvanized Following ASTM A 123 or any other stardand by client required.

4. Packing: Plastic bulble , Mat &Straw Bale or following client required

5. Length : within 16meters once forming( single section)

6. Thickness: from 1mm to 25mm

7. Shape: Conical.

8.  220kv

9. Easy install and maintenance.





Key Specification:


1. Material: Q235, Q345 or SS400 high quality Hot rolled steel or any special request is available.
2. Mounting Height: 3-40M Optional Mounting Height
3. Shape: Round conical; Octagonal conical; Straight Square; Polygonal; Tapered round
Shafts are made of steel sheet that folded into required shape and welded longitudinally by automatic arc welding machine
4. Brackets: Single or double brackets are in the shape and dimension as per customers requirement
5. Base plate: Base plate is square or round and size as customers' requirement
6. Base plate mounted: Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement
7. Ground mounted: The length buried underground as per customers requirement
8. Anticorrosion methods: Hot dip galvanized steel or hot dip galvanized with Plastic Powder Coating.
9. Shape: Round conical; Octagonal conical; Straight Square; Polygonal; Tapered roundGalvanizing: Hot dip galvanization with thickness of 80-100μm average
10. Powder coating: Pure polyester powder painting, color is optional
11. Other features: Short construction cycle, less land occupation, low overall cost and easy maintenance
12. Welding: Welding confirms with international welding standard of CWB
13. Certificate: ISO9001-2015
